Product Description
| Output |
| Output Power Capacity |
| 600 Watts / 1000 VA |
| Nominal Output Voltage |
| 120V |
| Output Frequency (sync to mains) |
| 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 |
| Topology |
| Line Interactive |
| Waveform Type |
| Stepped approximation to a sinewave |
| Output Connections |
| (4) NEMA 5-15R (Battery Backup) NEMA 5-15R |
| (4) NEMA 5-15R (Surge Protection) NEMA 5-15R |
|
|
| Input |
| Nominal Input Voltage |
| 120V |
| Input Frequency |
| 50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connections |
| NEMA 5-15P NEMA 5-15P |
| Cord Length |
| 1.83 meters |
| Maximum Input Current |
| 12A |
| Input Breaker Capacity |
| 15.0 A |
|
|
| Batteries & Runtime |
| Battery Type |
| Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
| Typical recharge time |
| 8 hour(s) |
| Replacement Battery |
| APCRBC123, APCRBC123J |
| RBC™ Quantity |
| 1 |
|
|
| Physical |
| Maximum Height |
| 250.00 mm |
| Maximum Width |
| 100.00 mm |
| Maximum Depth |
| 382.00 mm |
| Net Weight |
| 10.72 KG |
| Shipping Weight |
| 11.70 KG |
| Shipping Height |
| 337.00 mm |
| Shipping Width |
| 225.00 mm |
| Shipping Depth |
| 487.00 mm |
| Master Carton Units |
| 1.00 |
| Color |
| Black |
| SCC Codes |
| 1073130427878 5 |
| Units per Pallet |
| 32.00 |
| Pallet Dimensions |
| 46 inches |
| Pallet Weight |
| 393.28 KG |
